In early 2023, security researchers uncovered a significant flaw in the Windows operating system—CVE-2023-21674. This vulnerability, rooted in the Advanced Local Procedure Call (ALPC) system, allows attackers to escalate their privileges on a Windows machine, potentially taking full control. In this article, we'll break down how this vulnerability works, see some sample code, and guide you through the main exploit trigger. All technical details are simplified to help you understand how dangerous this flaw is and why patching is critical.

What is ALPC?

ALPC stands for Advanced Local Procedure Call. It's a core Windows feature that lets different programs—the client and server—communicate securely, quickly, and reliably. ALPC is often used by system services and kernel components to process requests from user apps. Because ALPC tends to run with higher privileges, vulnerabilities here are critical: if a hacker can trick ALPC, they might turn limited access into full system control.

About CVE-2023-21674

CVE-2023-21674 is an *Elevation of Privilege (EoP)* vulnerability affecting many versions of Windows, including Windows 10, Windows 11, and Windows Server. What makes this bug dangerous is that a local user (even with little permission) can run specially crafted code to gain SYSTEM-level privileges—the highest on Windows computers.

Microsoft’s Security Bulletin

- Microsoft Security Update Guide - CVE-2023-21674

From the official advisory

> An attacker who successfully exploited this vulnerability could gain SYSTEM privileges. An attacker must already have access to the target system, but exploitation is considered 'Low Complexity'.

The Technical Details: What’s the Bug?

At its core, the bug appears because of how Windows ALPC kernels manage memory, especially with "handle tables" used to track requests and resources. With the right timing and knowledge, an attacker can trick the system into using or freeing certain memory in dangerous ways (*use-after-free* bug), leading to code execution with high privileges.

Manipulate the ALPC message to force mishandling in the Windows kernel.

3. Trigger the use-after-free condition, overwriting sensitive memory like process tokens (which control user permissions).

Exploit Example: Privesc in Action

While a full, weaponized proof-of-concept (PoC) is too risky to share, here’s a simplified code snippet showing the ALPC interaction flow. This does not exploit the bug, but it gives insight into how communication is set up.

#include <windows.h>
#include <stdio.h>

// Minimal ALPC message structure for demonstration
typedef struct _ALPC_PORT_ATTRIBUTES {
    ULONG Flags;
    SECURITY_QUALITY_OF_SERVICE SecurityQos;
    SIZE_T MaxMessageLength;
    SIZE_T MemoryBandwidth;
    SIZE_T MaxPoolUsage;
    SIZE_T MaxSectionSize;
    SIZE_T MaxViewSize;
    SIZE_T MaxTotalSectionSize;
    ULONG DupObjectTypes;
#if defined(_WIN64)
    ULONG Reserved;
#endif
} ALPC_PORT_ATTRIBUTES, *PALPC_PORT_ATTRIBUTES;

int main() {
    HANDLE hPort;
    ALPC_PORT_ATTRIBUTES portAttr = {};
    UNICODE_STRING PortName;

    // This port name is just for demo - real-world use cases set up special names
    RtlInitUnicodeString(&PortName, L"\\RPC Control\\DemoPort");

    // NtAlpcCreatePort creates an ALPC port for client-server communication
    NTSTATUS status = NtAlpcCreatePort(&hPort, &PortName, &portAttr);
    if (!NT_SUCCESS(status)) {
        printf("Failed to create ALPC port: x%08X\n", status);
        return -1;
    }

    printf("ALPC port created. Handle: %p\n", hPort);

    // In a real exploit, this port would now be used to send 'evil' messages
    // to trigger the kernel bug.

    CloseHandle(hPort);
    return ;
}

*This sample assumes you have the required headers and privilege to call these APIs.*

Craft a malicious ALPC message—Abusing how message memory gets freed and reassigned.

3. Hit the race condition/use-after-free—This is the tricky part and needs deep knowledge of Windows internals.
4. Overwrite privileged kernel structures—Often replacing a security token, making your process act like SYSTEM.

Launch a new process (like Command Prompt) as SYSTEM—Enjoy full control over the computer.

Note: Full exploitation requires deep technical skills and isn't possible from the snippet above. Many public exploits are cleaned or only partially released to prevent widespread abuse.

Real-World Attacks and Threats

Microsoft and multiple security vendors found that this vulnerability was actively exploited in the wild as a *zero-day*—meaning attackers knew about and abused it before most users could patch.

What can you do?

- Patch Windows immediately: Windows Update Guide

References and Further Reading

- Microsoft Security Bulletin: CVE-2023-21674
- Google Project Zero’s write-up – deep technical dive
- SecurityWeek coverage

Conclusion

CVE-2023-21674 is a textbook example of how powerful, trusted Windows features can open the door for attackers when bugs slip in. Exploiting ALPC vulnerabilities requires technical skill, but the rewards (SYSTEM privileges) are huge. Luckily, Microsoft fixed the hole shortly after discovery. If you haven't already, update your systems now.

Stay safe!

*This post is exclusive and written in plain English for anyone wanting to learn about this important vulnerability. If you’re interested in more hands-on examples or deeper technical details, check out the references above.*
